Pipe Color Code Standards

Pipes are used in facilities to transport liquids and gasses from one place to another, both short and long distances. Most facilities have dozens of pipes moving substances from place to place and because of this, it is important to be able to keep track of the contents in each pipe as well as its destination. Following pipe color-coding is extremely helpful for obtaining crucial information about a pipe’s contents. If color codes are ignored, employees are at a higher risk of causing an accident that may result in physical harm as well as facility damage. For example, if a worker opens a pipe that is not identified correctly, he or she may expect clean water but instead open a valve to find toxic chemicals.

ANSI/ASME A13.1 Pipe Marking Standard

Pipe color-coding is not a complicated process, especially if industry standards are used. There are many standards out there from a variety of sources, but by far the most popular is the ANSI/ASME A13.1 standard. This standard explains colors, text, size, and placement of pipe marking labels. Following this type of color-coding standard makes it easy to offer training to employees and also helps ensure different departments within a facility are all using the same colors for their pipes. Not only that, but ANSI is such a well-respected and trusted organizations that their voluntary standards are applied by numerous industries without hesitation.

Colors, Words, and Symbols

Whenever labeling pipes, it is important to put all necessary information on the label. The color of a label is one of the most important label features because people will be able to see it from a distance. Most pipe markings, however, also include the following components: Words - Writing out the contents of the pipe is important. These words should be easy to read, so choose a simple font. Symbols - Most pipe markings will also have a symbol. In the United States, this is usually an arrow that points in the direction the contents in the pipe are flowing. A label can also have common warning symbols to alert people to potential dangers; this is common in Europe. When using pipe markings, a facility must choose to either buy generic pipe markings, special order custom pipe markings, or obtain blank pipe markings that can be printed on using an industrial label printer. Each of these options can be effective, but for facilities that have lots of pipes, a label maker is going to be the ideal option. On the other hand, for those who need just a few labels, special ordering is likely the best choice.

ANSI/ASME A13.1 Pipe Color Code Standards Explained

Businesses should familiarize themselves with the ANSI/ASME A13.1 pipe color code standard, which is the industry consensus standard for marking pipes. This standard identifies the color of the labels and what those colors mean. The following are the main options for this set of standards: Yellow with Black Lettering - This option is used for any pipe that contains flammable and oxidizing liquids and gasses. This could include gasoline, oils, and many others. Green with White Lettering - Using a green label with white lettering means that the pipe contains potable water. It could be used for cooling, feeding boilers, or even going to drinking fountains or sinks.
